Mfg. Part Number
71AF30-02-1-06S
Manufacturer
Product Category
Rotary Switches
Brief Description
SWITCH ROTARY
Datasheet Download
71AF30-02-1-06S.pdf
Availability of 71AF30-02-1-06S

Available Quantity

5020 Pieces

Can ship today


Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 24.39320
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of 71AF30-02-1-06S, we specialize in Grayhill, Inc. all series electronic components. 71AF30-02-1-06S can be shipped within 24 hours after order. If you have any demands for 71AF30-02-1-06S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
71AF30-02-1-06S Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of 71AF30-02-1-06S
Internal Part NumberEIS-71AF30-02-1-06S
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
PCN OtherMultiple Devices Plating Material 30/Jan/2015
Standard Package25
Category Switches
FamilyRotary Switches
Series71
Number of Positions6
Index StopsFixed
Number of Decks2
Number of Poles per Deck1
Circuit per DeckSP6T
Contact TimingShorting (MBB)
Current Rating250mA (AC/DC)
Voltage Rating - AC115V
Voltage Rating - DC30V
Actuator TypeFlatted (3.17mm Dia)
Actuator Length9.53mm
Angle of Throw30°
Contact MaterialSilver Alloy
Contact Finish-
Mounting TypePanel Mount, Through Hole, Right Angle
Termination StylePC Pin
Features-
Depth Behind Panel24.87mm
Panel Cutout Dimensions-
Operating Force, Torque4 ~ 32 in-oz
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)71AF30-02-1-06S
Related Links71AF30-, 71AF30-02-1-06S Datasheet, Grayhill, Inc. Distributor
71AF30-02-1-06S Details Description
