C&K Components 7201SPYAV2BE2
- Mfg. Part Number
- 7201SPYAV2BE2
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 0.4VA 20V
- Datasheet Download
- 7201SPYAV2BE2.pdf
Availability of 7201SPYAV2BE2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.17580
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7201SPYAV2BE2, we specialize in C&K Components all series electronic components. 7201SPYAV2BE2 can be shipped within 24 hours after order. If you have any demands for 7201SPYAV2BE2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7201SPYAV2BE2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7201SPYAV2BE2
| Internal Part Number | EIS-7201SPYAV2BE2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Anti-Rotation | |
| Actuator Length | 10.67mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Right Angle, Vertical | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Black Actuator | |
| Actuator Material | Brass | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7201SPYAV2BE2 | |
| Related Links | 7201SP, 7201SPYAV2BE2 Datasheet, C&K Components Distributor | |
7201SPYAV2BE2 Details Description
