C&K Components 7415P3D9CQE
- Mfg. Part Number
- 7415P3D9CQE
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DP3T 5A 120V
- Datasheet Download
- 7415P3D9CQE.pdf
Availability of 7415P3D9CQE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 19.86100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 7415P3D9CQE, we specialize in C&K Components all series electronic components. 7415P3D9CQE can be shipped within 24 hours after order. If you have any demands for 7415P3D9CQE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 7415P3D9CQE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
7415P3D9CQE
| Internal Part Number | EIS-7415P3D9CQE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | DP3T | |
| Switch Function | Mom-On-Mom | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flat Anti-Rotation | |
| Actuator Length | 13.21mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Jumper needed to achieve triple throw | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 7415P3D9CQE | |
| Related Links | 7415P, 7415P3D9CQE Datasheet, C&K Components Distributor | |
7415P3D9CQE Details Description
