Fairchild Semiconductor 74ACT02PC
- Mfg. Part Number
- 74ACT02PC
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE NOR 4CH 2-INP 14-DIP
- Datasheet Download
- 74ACT02PC.pdf
Availability of 74ACT02PC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 74ACT02PC, we specialize in Fairchild Semiconductor all series electronic components. 74ACT02PC can be shipped within 24 hours after order. If you have any demands for 74ACT02PC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 74ACT02PC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
74ACT02PC
| Internal Part Number | EIS-74ACT02PC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 74ACT | |
| Packaging | Tube | |
| Logic Type | NOR Gate | |
| Number of Circuits | 4 | |
| Number of Inputs | 2 | |
| Features | - | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Current - Quiescent (Max) | 4µA | |
| Current - Output High, Low | 24mA, 24mA | |
| Logic Level - Low | 0.8V | |
| Logic Level - High | 2V | |
| Max Propagation Delay @ V, Max CL | 9.5ns @ 5V, 50pF | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Supplier Device Package | 14-DIP | |
| Package / Case | 14-DIP (0.300", 7.62mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 74ACT02PC | |
| Related Links | 74AC, 74ACT02PC Datasheet, Fairchild Semiconductor Distributor | |
74ACT02PC Details Description
