NXP Semiconductors/Freescale Semiconductor, Inc. 74LVC541ADB,112
- Mfg. Part Number
- 74LVC541ADB,112
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Logic - Buffers, Drivers, Receivers, Transceivers
- Brief Description
- IC BUFF/DVR TRI-ST 8BIT 20SSOP
- Datasheet Download
- 74LVC541ADB,112.pdf
Availability of 74LVC541ADB,112
Available Quantity
9560 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.25313
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 74LVC541ADB,112, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. 74LVC541ADB,112 can be shipped within 24 hours after order. If you have any demands for 74LVC541ADB,112, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 74LVC541ADB,112 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
74LVC541ADB,112
| Internal Part Number | EIS-74LVC541ADB,112 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Logic Packages | |
| PCN Assembly/Origin | ICN6 to ICN8 Transfer 13/Jul/2013 | |
| PCN Packaging | Date Code Extended 18/Jul/2013 | |
| Standard Package | 66 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers | |
| Series | 74LVC | |
| Packaging | Tube | |
| Logic Type | Buffer/Line Driver, Non-Inverting | |
| Number of Elements | 1 | |
| Number of Bits per Element | 8 | |
| Current - Output High, Low | 24mA, 24mA | |
| Voltage - Supply | 1.65 V ~ 3.6 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 20-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 74LVC541ADB,112 | |
| Related Links | 74LVC54, 74LVC541ADB,112 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
74LVC541ADB,112 Details Description
