Qualtek Electronics Corp. 770W-X2/10
- Mfg. Part Number
- 770W-X2/10
- Manufacturer
- Qualtek Electronics Corp.
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- CONN RECEPT PANEL/R/A PCB PINS
- Datasheet Download
- 770W-X2/10.pdf
Availability of 770W-X2/10
Available Quantity
8759 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.33133
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 770W-X2/10, we specialize in Qualtek Electronics Corp. all series electronic components. 770W-X2/10 can be shipped within 24 hours after order. If you have any demands for 770W-X2/10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 770W-X2/10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
770W-X2/10
| Internal Part Number | EIS-770W-X2/10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | IEC Connector Designations | |
| Featured Product | AC Receptacles | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | 770W | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C8, Non-Polarized | |
| Connector Type | Receptacle, Male Pins | |
| Current - IEC | 2.5A | |
| Voltage - IEC | 250VAC | |
| Current - UL | - | |
| Voltage - UL | - | |
| Filter Type | Unfiltered - Commercial | |
| Fuse | No | |
| Number of Positions | 2 | |
| Mounting Type | Panel Mount, Snap-In; Through Hole, Right Angle | |
| Termination | Solder | |
| Switch Features | - | |
| Features | Board Lock | |
| Fuse Holder, Drawer | - | |
| Panel Cutout Dimensions | - | |
| Panel Thickness | - | |
| Material Flammability Rating | - | |
| Ingress Protection | - | |
| Approvals | CSA, UL, VDE | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 770W-X2/10 | |
| Related Links | 770W-, 770W-X2/10 Datasheet, Qualtek Electronics Corp. Distributor | |
