Texas Instruments 78ST136HC
- Mfg. Part Number
- 78ST136HC
- Manufacturer
- Texas Instruments
- Product Category
- DC DC Converters
- Brief Description
- REGULATOR 3.60V HORIZONTAL
- Datasheet Download
- 78ST136HC.pdf
Availability of 78ST136HC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 78ST136HC, we specialize in Texas Instruments all series electronic components. 78ST136HC can be shipped within 24 hours after order. If you have any demands for 78ST136HC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 78ST136HC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
78ST136HC
| Internal Part Number | EIS-78ST136HC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | 78ST100 | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 7V | |
| Voltage - Input (Max) | 26V | |
| Voltage - Output 1 | 3.6V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 1.5A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | OTP, SCP | |
| Mounting Type | Through Hole, Right Angle | |
| Package / Case | 3-SIP Module | |
| Size / Dimension | 0.94" L x 0.90" W x 0.31" H (23.9mm x 22.9mm x 7.9mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | - | |
| Power (Watts) - Max | 5.4W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 78ST136HC | |
| Related Links | 78ST, 78ST136HC Datasheet, Texas Instruments Distributor | |
78ST136HC Details Description
