FFF 8609342E113755E1LF
- Mfg. Part Number
- 8609342E113755E1LF
- Manufacturer
- FFF
- Product Category
- Backplane Connectors - DIN 41612
- Brief Description
- DIN RA HEADER F
- Datasheet Download
- 8609342E113755E1LF.pdf
Availability of 8609342E113755E1LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.85277
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 8609342E113755E1LF, we specialize in FFF all series electronic components. 8609342E113755E1LF can be shipped within 24 hours after order. If you have any demands for 8609342E113755E1LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 8609342E113755E1LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
8609342E113755E1LF
| Internal Part Number | EIS-8609342E113755E1LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | 8609 Series Color 25/Nov/2009 | |
| Standard Package | 192 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - DIN 41612 | |
| Series | 8609 | |
| Packaging | Tray | |
| Connector Type | Header, Male Pins | |
| Number of Positions | 48 (42 + 6 Power) | |
| Number of Positions Loaded | 42 | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 3 | |
| Style | M | |
| Level, Class | 2 | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Current Rating | 1.5A | |
| Material Flammability Rating | UL94 V-0 | |
| Material - Insulation | Polyester Thermoplastic | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 8609342E113755E1LF | |
| Related Links | 8609342E1, 8609342E113755E1LF Datasheet, FFF Distributor | |
8609342E113755E1LF Details Description
