Mill-Max 940-99-068-24-000000
- Mfg. Part Number
- 940-99-068-24-000000
- Manufacturer
- Mill-Max
- Product Category
- Sockets for ICs, Transistors
- Brief Description
- CONN SOCKET PLCC 68POS TIN-LEAD
- Datasheet Download
- 940-99-068-24-000000.pdf
Availability of 940-99-068-24-000000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 940-99-068-24-000000, we specialize in Mill-Max all series electronic components. 940-99-068-24-000000 can be shipped within 24 hours after order. If you have any demands for 940-99-068-24-000000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 940-99-068-24-000000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
940-99-068-24-000000
| Internal Part Number | EIS-940-99-068-24-000000 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 19 | |
| Category | Connectors, Interconnects | |
| Family | Sockets for ICs, Transistors | |
| Series | 940 | |
| Packaging | Tube | |
| Type | PLCC | |
| Number of Positions or Pins (Grid) | 68 (4 x 17) | |
| Pitch - Mating | 0.100" (2.54mm) | |
| Contact Finish - Mating | Tin-Lead | |
| Contact Finish Thickness - Mating | 100µin (2.54µm) | |
| Contact Material - Mating | Beryllium Copper | |
| Mounting Type | Through Hole | |
| Features | Closed Frame | |
| Termination | Solder | |
| Pitch - Post | 0.100" (2.54mm) | |
| Contact Finish - Post | Tin-Lead | |
| Contact Finish Thickness - Post | 200µin (5.08µm) | |
| Contact Material - Post | Brass Alloy | |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester | |
| Operating Temperature | -55°C ~ 125°C | |
| Termination Post Length | 0.130" (3.30mm) | |
| Material Flammability Rating | - | |
| Current Rating | 3A | |
| Contact Resistance | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 940-99-068-24-000000 | |
| Related Links | 940-99-068, 940-99-068-24-000000 Datasheet, Mill-Max Distributor | |
940-99-068-24-000000 Details Description
