Eaton (formerly Cooper Bussmann) A20220507L1
- Mfg. Part Number
- A20220507L1
- Manufacturer
- Eaton (formerly Cooper Bussmann)
- Product Category
- Terminal Blocks - Barrier Blocks
- Brief Description
- CONN BARRIER STRIP 5CIRC .375
- Datasheet Download
- A20220507L1.pdf
Availability of A20220507L1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.16000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A20220507L1, we specialize in Eaton (formerly Cooper Bussmann) all series electronic components. A20220507L1 can be shipped within 24 hours after order. If you have any demands for A20220507L1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A20220507L1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A20220507L1
| Internal Part Number | EIS-A20220507L1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Barrier Blocks | |
| Series | A2000 | |
| Packaging | Bulk | |
| Terminal Block Type | Barrier Block | |
| Number of Circuits | 5 | |
| Number of Wire Entries | 5 | |
| Pitch | 0.375" (9.53mm) | |
| Number of Rows | 1 | |
| Current Rating | 30A | |
| Voltage Rating | 300V | |
| Wire Gauge | 12-22 AWG | |
| Top Termination | Screws with Captive Plate | |
| Bottom Termination | PC Pin | |
| Barrier Type | 2 Wall (Dual) | |
| Features | Positions Stamped | |
| Color | Black | |
| Terminal Screw Material | Steel | |
| Terminal Screw Finish | - | |
| Mounting Type | Through Hole | |
| Operating Temperature | -40°C ~ 105°C | |
| Material - Insulation | Thermoplastic | |
| Material Flammability Rating | UL94 V-0 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A20220507L1 | |
| Related Links | A2022, A20220507L1 Datasheet, Eaton (formerly Cooper Bussmann) Distributor | |
A20220507L1 Details Description
