Omron Automation & Safety A22TK-2RL-02-K01
- Mfg. Part Number
- A22TK-2RL-02-K01
- Manufacturer
- Omron Automation & Safety
- Product Category
- Keylock Switches
- Brief Description
- A22TK-2RL-02-K01
- Datasheet Download
- A22TK-2RL-02-K01.pdf
Availability of A22TK-2RL-02-K01
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 162.69000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A22TK-2RL-02-K01, we specialize in Omron Automation & Safety all series electronic components. A22TK-2RL-02-K01 can be shipped within 24 hours after order. If you have any demands for A22TK-2RL-02-K01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A22TK-2RL-02-K01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A22TK-2RL-02-K01
| Internal Part Number | EIS-A22TK-2RL-02-K01 | |
| Lead Free Status / RoHS Status | Vendor undefined / Vendor undefined | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Keylock Switches | |
| Series | A22TK | |
| Circuit | DPST-NC | |
| Number of Positions | 2 | |
| Switch Function | On-Off | |
| Contact Timing | Not Specified | |
| Current Rating | 10A (AC/DC) | |
| Voltage Rating - AC | 110V | |
| Voltage Rating - DC | 24V | |
| Actuator Type | Tubular Key | |
| Key Removable Positions | Right | |
| Angle of Throw | 90° | |
| Contact Material | - | |
| Contact Finish | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Screw Terminal | |
| Panel Cutout Dimensions | Circular - 22.30mm Dia | |
| Features | IP65 | |
| Depth Behind Flange | 54.70mm | |
| Operating Temperature | -20°C ~ 70°C | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A22TK-2RL-02-K01 | |
| Related Links | A22TK-2R, A22TK-2RL-02-K01 Datasheet, Omron Automation & Safety Distributor | |
A22TK-2RL-02-K01 Details Description
