TE Connectivity AMP Connectors A3AAH-1036M
- Mfg. Part Number
- A3AAH-1036M
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Rectangular Cable Assemblies
- Brief Description
- IDC CABLE - ASC10H/AE10M/ASC10H
- Datasheet Download
- A3AAH-1036M.pdf
Availability of A3AAH-1036M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.54634
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A3AAH-1036M, we specialize in TE Connectivity AMP Connectors all series electronic components. A3AAH-1036M can be shipped within 24 hours after order. If you have any demands for A3AAH-1036M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A3AAH-1036M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A3AAH-1036M
| Internal Part Number | EIS-A3AAH-1036M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Cable Assemblies | |
| Family | Rectangular Cable Assemblies | |
| Series | - | |
| Connector Type | Socket to Socket | |
| Number of Positions | 10 | |
| Number of Rows | 2 | |
| Pitch - Connector | 0.100" (2.54mm) | |
| Pitch - Cable | 0.050" (1.27mm) | |
| Length | 3.00' (914.40mm) | |
| Features | - | |
| Color | Multiple, Ribbon | |
| Shielding | Unshielded | |
| Usage | - | |
| Cable Termination | IDC | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 15µin (0.38µm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A3AAH-1036M | |
| Related Links | A3AAH, A3AAH-1036M Datasheet, TE Connectivity AMP Connectors Distributor | |
A3AAH-1036M Details Description
