Amphenol Pcd A8504952S14W
- Mfg. Part Number
- A8504952S14W
- Manufacturer
- Amphenol Pcd
- Product Category
- Circular Connectors - Backshells and Cable Clamps
- Brief Description
- CONN CABLE CLAMP SZ 14 OLIVE
- Datasheet Download
- A8504952S14W.pdf
Availability of A8504952S14W
Available Quantity
5039 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.98400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A8504952S14W, we specialize in Amphenol Pcd all series electronic components. A8504952S14W can be shipped within 24 hours after order. If you have any demands for A8504952S14W, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A8504952S14W Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A8504952S14W
| Internal Part Number | EIS-A8504952S14W | |
| Lead Free Status / RoHS Status | Lead free / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Plating Finishes | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Backshells and Cable Clamps | |
| Series | SAE AS85049 | |
| Type | Cable Clamp | |
| Cable Opening | 0.350" ~ 0.480" (8.89mm ~ 12.19mm) | |
| Diameter - Outside | 1.260" (32.00mm) | |
| Shell Size - Insert | 14 | |
| Thread Size | 7/8-20 UNEF | |
| Cable Exit | 180° | |
| Material | Aluminum Alloy | |
| Plating | Cadmium Nickel | |
| Shielding | - | |
| Color | Olive | |
| Features | Clamp Screws, Self-Locking | |
| Ingress Protection | - | |
| Includes | - | |
| Material Flammability Rating | - | |
| For Use With/Related Products | MIL-DTL-26482 Series II, MIL-DTL-5015 Series 3400, MIL-DTL-83723 Series I, III | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A8504952S14W | |
| Related Links | A85049, A8504952S14W Datasheet, Amphenol Pcd Distributor | |
A8504952S14W Details Description
