Omron A8L-21-13N1
- Mfg. Part Number
- A8L-21-13N1
- Manufacturer
- Omron
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER DPST 10A 125V
- Datasheet Download
- A8L-21-13N1.pdf
Availability of A8L-21-13N1
Available Quantity
5320 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.91970
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of A8L-21-13N1, we specialize in Omron all series electronic components. A8L-21-13N1 can be shipped within 24 hours after order. If you have any demands for A8L-21-13N1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- A8L-21-13N1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
A8L-21-13N1
| Internal Part Number | EIS-A8L-21-13N1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 300 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | A8L | |
| Packaging | Bulk | |
| Circuit | DPST | |
| Switch Function | On-Off | |
| Current Rating | 10A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Concave (Curved) | |
| Color - Actuator/Cap | Black | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In, Right Angle | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Rectangular - 19.20mm x 17.50mm | |
| Operating Temperature | -20°C ~ 55°C | |
| Mechanical Life | 50,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | A8L-21-13N1 | |
| Related Links | A8L-2, A8L-21-13N1 Datasheet, Omron Distributor | |
