Kingbright AA2810ASYS/J3
- Mfg. Part Number
- AA2810ASYS/J3
- Manufacturer
- Kingbright
- Product Category
- LED Indication - Discrete
- Brief Description
- LED YELLOW CLEAR 2SMD R/A
- Datasheet Download
- AA2810ASYS/J3.pdf
Availability of AA2810ASYS/J3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.26460
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AA2810ASYS/J3, we specialize in Kingbright all series electronic components. AA2810ASYS/J3 can be shipped within 24 hours after order. If you have any demands for AA2810ASYS/J3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AA2810ASYS/J3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AA2810ASYS/J3
| Internal Part Number | EIS-AA2810ASYS/J3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Optoelectronics | |
| Family | LED Indication - Discrete | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Color | Yellow | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | 600mcd | |
| Lens Style/Size | Rectangle with Flat Top, 2.30mm x 0.57mm | |
| Voltage - Forward (Vf) (Typ) | 2V | |
| Current - Test | 20mA | |
| Viewing Angle | 110° | |
| Mounting Type | Surface Mount, Right Angle | |
| Wavelength - Dominant | 590nm | |
| Wavelength - Peak | 590nm | |
| Features | - | |
| Package / Case | 2-SMD, J-Lead | |
| Supplier Device Package | SMD | |
| Size / Dimension | 2.80mm L x 1.20mm W | |
| Height (Max) | 0.80mm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AA2810ASYS/J3 | |
| Related Links | AA2810, AA2810ASYS/J3 Datasheet, Kingbright Distributor | |
AA2810ASYS/J3 Details Description
