Abracon Corporation AB-557-03-HCC-F-L-C-T3
- Mfg. Part Number
- AB-557-03-HCC-F-L-C-T3
- Manufacturer
- Abracon Corporation
- Product Category
- Clock/Timing - Application Specific
- Brief Description
- IC PCIE CLOCK GEN 100MHZ 14QFN
- Datasheet Download
- AB-557-03-HCC-F-L-C-T3.pdf
Availability of AB-557-03-HCC-F-L-C-T3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.90190
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AB-557-03-HCC-F-L-C-T3, we specialize in Abracon Corporation all series electronic components. AB-557-03-HCC-F-L-C-T3 can be shipped within 24 hours after order. If you have any demands for AB-557-03-HCC-F-L-C-T3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AB-557-03-HCC-F-L-C-T3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AB-557-03-HCC-F-L-C-T3
| Internal Part Number | EIS-AB-557-03-HCC-F-L-C-T3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | AB-557-03.pdfAB-557-03.stp | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Application Specific | |
| Series | Pure Silicon™ | |
| Packaging | Tape & Reel (TR) | |
| PLL | Yes | |
| Main Purpose | PCI Express (PCIe), Clock Generator | |
| Input | - | |
| Output | HCSL, LVCMOS | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 0:2 | |
| Differential - Input:Output | No/Yes | |
| Frequency - Max | 460MHz | |
| Voltage - Supply | 2.25 V ~ 3.6 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-VFQFN Exposed Pad | |
| Supplier Device Package | 14-QFN (3.2x2.5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AB-557-03-HCC-F-L-C-T3 | |
| Related Links | AB-557-03-H, AB-557-03-HCC-F-L-C-T3 Datasheet, Abracon Corporation Distributor | |
AB-557-03-HCC-F-L-C-T3 Details Description
