Sullins Connector Solutions ABB11DHBS
- Mfg. Part Number
- ABB11DHBS
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 22POS R/A .050 SLD
- Datasheet Download
- ABB11DHBS.pdf
Availability of ABB11DHBS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABB11DHBS, we specialize in Sullins Connector Solutions all series electronic components. ABB11DHBS can be shipped within 24 hours after order. If you have any demands for ABB11DHBS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABB11DHBS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABB11DHBS
| Internal Part Number | EIS-ABB11DHBS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 11 | |
| Number of Positions | 22 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.050" (1.27mm) | |
| Features | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder, Staggered | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Contact Type | Hairpin Bellows | |
| Color | Black | |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 150°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABB11DHBS | |
| Related Links | ABB1, ABB11DHBS Datasheet, Sullins Connector Solutions Distributor | |
ABB11DHBS Details Description
