Bel Fuse Inc. ABC120-1T12L
- Mfg. Part Number
- ABC120-1T12L
- Manufacturer
- Bel Fuse Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 12V 8.33A
- Datasheet Download
- ABC120-1T12L.pdf
Availability of ABC120-1T12L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 48.85920
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABC120-1T12L, we specialize in Bel Fuse Inc. all series electronic components. ABC120-1T12L can be shipped within 24 hours after order. If you have any demands for ABC120-1T12L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABC120-1T12L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABC120-1T12L
| Internal Part Number | EIS-ABC120-1T12L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | ABC Series Power Supplies ABC/MBC Low-Profile Series Power Supplies | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ABC120 | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 8.33A | |
| Power (Watts) | 100W (120W Forced Air) | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 90% | |
| Operating Temperature | -40°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, PFC, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.1mm) | |
| Minimum Load Required | - | |
| Approvals | CE | |
| Power (Watts) - Max | 100W (120W Forced Air) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABC120-1T12L | |
| Related Links | ABC120, ABC120-1T12L Datasheet, Bel Fuse Inc. Distributor | |
ABC120-1T12L Details Description
