Bel Fuse Inc. ABC75-1T15L
- Mfg. Part Number
- ABC75-1T15L
- Manufacturer
- Bel Fuse Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 15V 5A
- Datasheet Download
- ABC75-1T15L.pdf
Availability of ABC75-1T15L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 33.93000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABC75-1T15L, we specialize in Bel Fuse Inc. all series electronic components. ABC75-1T15L can be shipped within 24 hours after order. If you have any demands for ABC75-1T15L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABC75-1T15L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABC75-1T15L
| Internal Part Number | EIS-ABC75-1T15L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ABC75 | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 15V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 5A | |
| Power (Watts) | 75W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 90% | |
| Operating Temperature | -40°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, PFC, Standby Output, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 3.00" L x 2.00" W x 1.00" H (76.2mm x 50.8mm x 25.4mm) | |
| Minimum Load Required | No | |
| Approvals | CE | |
| Power (Watts) - Max | 75W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABC75-1T15L | |
| Related Links | ABC75, ABC75-1T15L Datasheet, Bel Fuse Inc. Distributor | |
ABC75-1T15L Details Description
