Abracon Corporation ABM2-29.4912MHZ-D4Y-T
- Mfg. Part Number
- ABM2-29.4912MHZ-D4Y-T
- Manufacturer
- Abracon Corporation
- Product Category
- Crystals
- Brief Description
- Crystal 29.4912MHz 30ppm 18pF 50 Ohm -40°C - 85°C Surface Mount 2-SMD
- Datasheet Download
- ABM2-29.4912MHZ-D4Y-T.pdf
Availability of ABM2-29.4912MHZ-D4Y-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.32200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABM2-29.4912MHZ-D4Y-T, we specialize in Abracon Corporation all series electronic components. ABM2-29.4912MHZ-D4Y-T can be shipped within 24 hours after order. If you have any demands for ABM2-29.4912MHZ-D4Y-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABM2-29.4912MHZ-D4Y-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABM2-29.4912MHZ-D4Y-T
| Internal Part Number | EIS-ABM2-29.4912MHZ-D4Y-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | ABM2.pdfABM2.stp | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Crystals | |
| Series | ABM2 | |
| Packaging | Tape & Reel (TR) | |
| Type | MHz Crystal | |
| Frequency | 29.4912MHz | |
| Frequency Stability | ±30ppm | |
| Frequency Tolerance | ±30ppm | |
| Load Capacitance | 18pF | |
| ESR (Equivalent Series Resistance) | 50 Ohm | |
| Operating Mode | Fundamental | |
| Operating Temperature | -40°C ~ 85°C | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 2-SMD | |
| Size / Dimension | 0.315" L x 0.177" W (8.00mm x 4.50mm) | |
| Height | 0.063" (1.60mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABM2-29.4912MHZ-D4Y-T | |
| Related Links | ABM2-29.49, ABM2-29.4912MHZ-D4Y-T Datasheet, Abracon Corporation Distributor | |
ABM2-29.4912MHZ-D4Y-T Details Description
