Abracon Corporation ABSM2-4.000MHZ-4-T
- Mfg. Part Number
- ABSM2-4.000MHZ-4-T
- Manufacturer
- Abracon Corporation
- Product Category
- Crystals
- Brief Description
- Crystal 4.0000MHz 30ppm 18pF 150 Ohm -10°C - 60°C Surface Mount 4-SOJ, 9.40mm pitch
- Datasheet Download
- ABSM2-4.000MHZ-4-T.pdf
Availability of ABSM2-4.000MHZ-4-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ABSM2-4.000MHZ-4-T, we specialize in Abracon Corporation all series electronic components. ABSM2-4.000MHZ-4-T can be shipped within 24 hours after order. If you have any demands for ABSM2-4.000MHZ-4-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ABSM2-4.000MHZ-4-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ABSM2-4.000MHZ-4-T
| Internal Part Number | EIS-ABSM2-4.000MHZ-4-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | ABSM2.pdfABSM2.stp | |
| PCN Obsolescence/ EOL | ABSM2 Series 30/Sep/2014 | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Crystals | |
| Series | ABSM2 | |
| Packaging | Tape & Reel (TR) | |
| Type | MHz Crystal | |
| Frequency | 4MHz | |
| Frequency Stability | ±50ppm | |
| Frequency Tolerance | ±30ppm | |
| Load Capacitance | 18pF | |
| ESR (Equivalent Series Resistance) | 150 Ohm | |
| Operating Mode | Fundamental | |
| Operating Temperature | -10°C ~ 60°C | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SOJ, 9.40mm pitch | |
| Size / Dimension | 0.492" L x 0.180" W (12.50mm x 4.60mm) | |
| Height | 0.146" (3.70mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ABSM2-4.000MHZ-4-T | |
| Related Links | ABSM2-4.0, ABSM2-4.000MHZ-4-T Datasheet, Abracon Corporation Distributor | |
ABSM2-4.000MHZ-4-T Details Description
