Sullins Connector Solutions ACM02DRXN
- Mfg. Part Number
- ACM02DRXN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 4POS DIP .156 SLD
- Datasheet Download
- ACM02DRXN.pdf
Availability of ACM02DRXN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.47500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ACM02DRXN, we specialize in Sullins Connector Solutions all series electronic components. ACM02DRXN can be shipped within 24 hours after order. If you have any demands for ACM02DRXN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ACM02DRXN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ACM02DRXN
| Internal Part Number | EIS-ACM02DRXN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tray | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 2 | |
| Number of Positions | 4 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | Full Bellows | |
| Color | Green | |
| Flange Feature | - | |
| Operating Temperature | -65°C ~ 150°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ACM02DRXN | |
| Related Links | ACM0, ACM02DRXN Datasheet, Sullins Connector Solutions Distributor | |
ACM02DRXN Details Description
