Analog AD5274BCPZ-100-RL7
- Mfg. Part Number
- AD5274BCPZ-100-RL7
- Manufacturer
- Analog
- Product Category
- Data Acquisition - Digital Potentiometers
- Brief Description
- IC RHEOSTAT 5V 50-TP 256 10LFCSP
- Datasheet Download
- AD5274BCPZ-100-RL7.pdf
Availability of AD5274BCPZ-100-RL7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.14000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD5274BCPZ-100-RL7, we specialize in Analog all series electronic components. AD5274BCPZ-100-RL7 can be shipped within 24 hours after order. If you have any demands for AD5274BCPZ-100-RL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD5274BCPZ-100-RL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD5274BCPZ-100-RL7
| Internal Part Number | EIS-AD5274BCPZ-100-RL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital Potentiometers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Taper | Linear | |
| Configuration | Rheostat | |
| Number of Circuits | 1 | |
| Number of Taps | 256 | |
| Resistance (Ohms) | 100k | |
| Interface | I²C | |
| Memory Type | Non-Volatile | |
| Voltage - Supply | 2.7 V ~ 5.5 V, ±2.5 V ~ 2.75 V | |
| Features | Selectable Address | |
| Tolerance | ±15% | |
| Temperature Coefficient (Typ) | 5 ppm/°C | |
| Resistance - Wiper (Ohms) (Typ) | 35 | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 10-WFDFN Exposed Pad, CSP | |
| Supplier Device Package | 10-LFCSP-WD (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD5274BCPZ-100-RL7 | |
| Related Links | AD5274BCP, AD5274BCPZ-100-RL7 Datasheet, Analog Distributor | |
AD5274BCPZ-100-RL7 Details Description
