Analog AD5338ARMZ-1
- Mfg. Part Number
- AD5338ARMZ-1
- Manufacturer
- Analog
- Product Category
- Data Acquisition - Digital to Analog Converters (DAC)
- Brief Description
- IC DAC 10BIT I2C/SRL 8MSOP
- Datasheet Download
- AD5338ARMZ-1.pdf
Availability of AD5338ARMZ-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.77910
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD5338ARMZ-1, we specialize in Analog all series electronic components. AD5338ARMZ-1 can be shipped within 24 hours after order. If you have any demands for AD5338ARMZ-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD5338ARMZ-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD5338ARMZ-1
| Internal Part Number | EIS-AD5338ARMZ-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Fundamentals DAC Architectures Five Things to Know About DACs Part 1: Resolution vs. Accuracy Five Things to Know About DACs Part 2: Total Unadjusted Error (TUE) Five Things to Know About DACs Part 5: Dynamic Performance Five Things to Know About DACs Part 4: Buffering | |
| PCN Assembly/Origin | Assembly Site Addition 05/Jan/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital to Analog Converters (DAC) | |
| Series | - | |
| Packaging | Tube | |
| Settling Time | 7µs | |
| Number of Bits | 10 | |
| Data Interface | I²C | |
| Number of Converters | 2 | |
| Voltage Supply Source | Single Supply | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 8-MSOP | |
| Number of Outputs and Type | 2 Voltage | |
| Sampling Rate (Per Second) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD5338ARMZ-1 | |
| Related Links | AD5338, AD5338ARMZ-1 Datasheet, Analog Distributor | |
