Analog AD5684BCPZ-RL7
- Mfg. Part Number
- AD5684BCPZ-RL7
- Manufacturer
- Analog
- Product Category
- Data Acquisition - Digital to Analog Converters (DAC)
- Brief Description
- IC DAC 12BIT SPI QUAD 16LFCSP
- Datasheet Download
- AD5684BCPZ-RL7.pdf
Availability of AD5684BCPZ-RL7
Available Quantity
7282 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.48800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD5684BCPZ-RL7, we specialize in Analog all series electronic components. AD5684BCPZ-RL7 can be shipped within 24 hours after order. If you have any demands for AD5684BCPZ-RL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD5684BCPZ-RL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD5684BCPZ-RL7
| Internal Part Number | EIS-AD5684BCPZ-RL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Five Things to Know About DACs Part 4: Buffering | |
| Featured Product | AD568x and AD569x nanoDAC® 2nd Quarter Select Products | |
| PCN Design/Specification | AD531x,AD568x,AD569x Datasheet Update 20/Jan/2014 | |
| PCN Assembly/Origin | LFCSP 2x3,3x3 Assembly Test Site Transfer 18/Oct/2013 Assembly/Test Site Revision B 28/Apr/2014 Assembly/Test Site Revision C 06/Aug/2014 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital to Analog Converters (DAC) | |
| Series | nanoDAC+® | |
| Packaging | Cut Tape (CT) | |
| Settling Time | 7µs | |
| Number of Bits | 12 | |
| Data Interface | DSP, MICROWIRE™, QSPI™, Serial, SPI™ | |
| Number of Converters | 4 | |
| Voltage Supply Source | Analog and Digital | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-WFQFN Exposed Pad, CSP | |
| Supplier Device Package | 16-LFCSP-WQ (3x3) | |
| Number of Outputs and Type | 4 Voltage | |
| Sampling Rate (Per Second) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD5684BCPZ-RL7 | |
| Related Links | AD5684B, AD5684BCPZ-RL7 Datasheet, Analog Distributor | |
