Analog AD8065AR
- Mfg. Part Number
- AD8065AR
- Manufacturer
- Analog
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP VFB 145MHZ RRO 8SOIC
- Datasheet Download
- AD8065AR.pdf
Availability of AD8065AR
Available Quantity
5224 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.31040
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD8065AR, we specialize in Analog all series electronic components. AD8065AR can be shipped within 24 hours after order. If you have any demands for AD8065AR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD8065AR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD8065AR
| Internal Part Number | EIS-AD8065AR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Pulse Oximeter Solution | |
| Product Training Modules | Common Photodiode Op-Amp Circuit Problems and Solutions Indirect Current Feedback Instrumentation Amplifier Applications Guide | |
| Design Resources | Unipolar, Precision DC Digital-to-Analog Conversion Using AD5426/32/43 8-Bit to12-Bit DACs (CN0034) Programmable Gain Element Using AD5426/32/43 Current Output DACs (CN0038) Programmable Gain Element Using AD5450/1/2/3 Current Output DAC Family (CN0055) | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 98 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | FastFET™ | |
| Packaging | Tube | |
| Amplifier Type | Voltage Feedback | |
| Number of Circuits | 1 | |
| Output Type | Rail-to-Rail | |
| Slew Rate | 180 V/µs | |
| Gain Bandwidth Product | - | |
| -3db Bandwidth | 145MHz | |
| Current - Input Bias | 3pA | |
| Voltage - Input Offset | 400µV | |
| Current - Supply | 6.6mA | |
| Current - Output / Channel | 30mA | |
| Voltage - Supply, Single/Dual (±) | 5 V ~ 24 V, ±2.5 V ~ 12 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD8065AR | |
| Related Links | AD80, AD8065AR Datasheet, Analog Distributor | |
AD8065AR Details Description
