Analog AD9268BCPZRL7-80
- Mfg. Part Number
- AD9268BCPZRL7-80
- Manufacturer
- Analog
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 16BIT SRL 80MSPS 64LFCSP
- Datasheet Download
- AD9268BCPZRL7-80.pdf
Availability of AD9268BCPZRL7-80
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 124.04400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AD9268BCPZRL7-80, we specialize in Analog all series electronic components. AD9268BCPZRL7-80 can be shipped within 24 hours after order. If you have any demands for AD9268BCPZRL7-80, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AD9268BCPZRL7-80 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AD9268BCPZRL7-80
| Internal Part Number | EIS-AD9268BCPZRL7-80 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 750 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 16 | |
| Sampling Rate (Per Second) | 80M | |
| Number of Inputs | 2 | |
| Input Type | Differential | |
| Data Interface | Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 2 | |
| Architecture | Pipelined | |
| Reference Type | External, Internal | |
| Voltage - Supply, Analog | 1.7 V ~ 1.9 V | |
| Voltage - Supply, Digital | 1.7 V ~ 1.9 V | |
| Features | Simultaneous Sampling | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 64-VFQFN Exposed Pad, CSP | |
| Supplier Device Package | 64-LFCSP-VQ (9x9) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AD9268BCPZRL7-80 | |
| Related Links | AD9268BC, AD9268BCPZRL7-80 Datasheet, Analog Distributor | |
AD9268BCPZRL7-80 Details Description
