Analog ADG702LBRJZ-REEL7
- Mfg. Part Number
- ADG702LBRJZ-REEL7
- Manufacturer
- Analog
- Product Category
- Interface - Analog Switches, Multiplexers, Demultiplexers
- Brief Description
- IC SWITCH SPST CMOS SOT23-5
- Datasheet Download
- ADG702LBRJZ-REEL7.pdf
Availability of ADG702LBRJZ-REEL7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADG702LBRJZ-REEL7, we specialize in Analog all series electronic components. ADG702LBRJZ-REEL7 can be shipped within 24 hours after order. If you have any demands for ADG702LBRJZ-REEL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADG702LBRJZ-REEL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADG702LBRJZ-REEL7
| Internal Part Number | EIS-ADG702LBRJZ-REEL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 29/Jan/2014 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Switch | |
| Circuit | 1 x SPST - NC | |
| On-State Resistance | 3 Ohm | |
| Voltage Supply Source | Single Supply | |
| Voltage - Supply, Single/Dual (±) | 1.8 V ~ 5.5 V | |
| Current - Supply | 1nA | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | SOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADG702LBRJZ-REEL7 | |
| Related Links | ADG702LB, ADG702LBRJZ-REEL7 Datasheet, Analog Distributor | |
ADG702LBRJZ-REEL7 Details Description
