Analog ADM211EAR
- Mfg. Part Number
- ADM211EAR
- Manufacturer
- Analog
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC TX/RX RS-232 5V 0.1UF 28SOIC
- Datasheet Download
- ADM211EAR.pdf
Availability of ADM211EAR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.16778
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADM211EAR, we specialize in Analog all series electronic components. ADM211EAR can be shipped within 24 hours after order. If you have any demands for ADM211EAR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADM211EAR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADM211EAR
| Internal Part Number | EIS-ADM211EAR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Alternate Wafer Fab 14/Jul/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 27 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tube | |
| Type | Transceiver | |
| Protocol | RS232 | |
| Number of Drivers/Receivers | 4/5 | |
| Duplex | Full | |
| Receiver Hysteresis | 650mV | |
| Data Rate | 120Kbps | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 28-SOIC W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADM211EAR | |
| Related Links | ADM2, ADM211EAR Datasheet, Analog Distributor | |
ADM211EAR Details Description
