Analog ADM3252EABCZ
- Mfg. Part Number
- ADM3252EABCZ
- Manufacturer
- Analog
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 2.5KV 2CH RS232 44BGA
- Datasheet Download
- ADM3252EABCZ.pdf
Availability of ADM3252EABCZ
Available Quantity
5125 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.47200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADM3252EABCZ, we specialize in Analog all series electronic components. ADM3252EABCZ can be shipped within 24 hours after order. If you have any demands for ADM3252EABCZ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADM3252EABCZ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADM3252EABCZ
| Internal Part Number | EIS-ADM3252EABCZ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Programmable Logic Controllers (PLCs) Solutions | |
| PCN Design/Specification | ADM3252E Power Die 01/Dec/2015 | |
| Standard Package | 1 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | IsoPower®, iCoupler® | |
| Packaging | Tray | |
| Technology | Magnetic Coupling | |
| Type | RS232 | |
| Isolated Power | Yes | |
| Number of Channels | 4 | |
| Inputs - Side 1/Side 2 | 2/2 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 460Kbps | |
| Propagation Delay tpLH / tpHL (Max) | - | |
| Pulse Width Distortion (Max) | - | |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns | |
| Voltage - Supply | 3.3V, 5V | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 44-LFBGA, CSPBGA | |
| Supplier Device Package | 44-CSPBGA (12x12) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADM3252EABCZ | |
| Related Links | ADM325, ADM3252EABCZ Datasheet, Analog Distributor | |
ADM3252EABCZ Details Description
