Analog ADP1196ACBZ-02-R7
- Mfg. Part Number
- ADP1196ACBZ-02-R7
- Manufacturer
- Analog
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC LOW-SIDE LOAD SWITCH 6WLCSP
- Datasheet Download
- ADP1196ACBZ-02-R7.pdf
Availability of ADP1196ACBZ-02-R7
Available Quantity
11020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.60000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADP1196ACBZ-02-R7, we specialize in Analog all series electronic components. ADP1196ACBZ-02-R7 can be shipped within 24 hours after order. If you have any demands for ADP1196ACBZ-02-R7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADP1196ACBZ-02-R7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADP1196ACBZ-02-R7
| Internal Part Number | EIS-ADP1196ACBZ-02-R7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side or Low Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 1.83 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 3A | |
| Rds On (Typ) | 10 mOhm | |
| Input Type | Non-Inverting | |
| Features | Slew Rate Controlled | |
| Fault Protection | Current Limiting (Fixed), Over Temperature | |
| Operating Temperature | -40°C ~ 105°C (TJ) | |
| Package / Case | 6-WFBGA, WLCSP | |
| Supplier Device Package | 6-WLCSP (1.45x0.95) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADP1196ACBZ-02-R7 | |
| Related Links | ADP1196A, ADP1196ACBZ-02-R7 Datasheet, Analog Distributor | |
