Analog ADP121-ACBZ15R7
- Mfg. Part Number
- ADP121-ACBZ15R7
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 1.5V 0.15A 4WLCSP
- Datasheet Download
- ADP121-ACBZ15R7.pdf
Availability of ADP121-ACBZ15R7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.41230
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADP121-ACBZ15R7, we specialize in Analog all series electronic components. ADP121-ACBZ15R7 can be shipped within 24 hours after order. If you have any demands for ADP121-ACBZ15R7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADP121-ACBZ15R7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADP121-ACBZ15R7
| Internal Part Number | EIS-ADP121-ACBZ15R7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Activity Monitoring Solution Pulse Oximeter Solution Electrocardiogram (ECG) Solutions | |
| Product Training Modules | Low Drop Out (LDO) Regulators | |
| Design Resources | Low power, Long Range, ISM Wireless Measuring Node (CN0164) | |
| PCN Packaging | WLCSP Devices/8mm 28/Feb/2012 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 1.5V | |
| Current - Output | 150mA | |
| Voltage - Dropout (Typical) | - | |
| Number of Regulators | 1 | |
| Voltage - Input | 2.3 V ~ 5.5 V | |
| Current - Limit (Min) | 160mA | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-WFBGA, WLCSP | |
| Supplier Device Package | 4-WLCSP (0.82x0.82) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADP121-ACBZ15R7 | |
| Related Links | ADP121-, ADP121-ACBZ15R7 Datasheet, Analog Distributor | |
ADP121-ACBZ15R7 Details Description
