Analog ADP2108ACBZ-1.82R7
- Mfg. Part Number
- ADP2108ACBZ-1.82R7
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK 1.82V 0.6A 5WLCSP
- Datasheet Download
- ADP2108ACBZ-1.82R7.pdf
Availability of ADP2108ACBZ-1.82R7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.76950
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADP2108ACBZ-1.82R7, we specialize in Analog all series electronic components. ADP2108ACBZ-1.82R7 can be shipped within 24 hours after order. If you have any demands for ADP2108ACBZ-1.82R7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADP2108ACBZ-1.82R7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADP2108ACBZ-1.82R7
| Internal Part Number | EIS-ADP2108ACBZ-1.82R7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Pressure Transmitter Solutions Pulse Oximeter Solution Electrocardiogram (ECG) Solutions | |
| PCN Packaging | WLCSP Devices/8mm 28/Feb/2012 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Fixed | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.3V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 1.82V | |
| Voltage - Output (Max) | - | |
| Current - Output | 600mA | |
| Frequency - Switching | 3MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 5-WFBGA, WLCSP | |
| Supplier Device Package | 5-WLCSP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADP2108ACBZ-1.82R7 | |
| Related Links | ADP2108AC, ADP2108ACBZ-1.82R7 Datasheet, Analog Distributor | |
ADP2108ACBZ-1.82R7 Details Description
