Analog ADP322ACPZ-135-R7
- Mfg. Part Number
- ADP322ACPZ-135-R7
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 3.3/2.5/1.8V 16LFCSP
- Datasheet Download
- ADP322ACPZ-135-R7.pdf
Availability of ADP322ACPZ-135-R7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.92340
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADP322ACPZ-135-R7, we specialize in Analog all series electronic components. ADP322ACPZ-135-R7 can be shipped within 24 hours after order. If you have any demands for ADP322ACPZ-135-R7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADP322ACPZ-135-R7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADP322ACPZ-135-R7
| Internal Part Number | EIS-ADP322ACPZ-135-R7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | RF Signal Source Solutions | |
| PCN Assembly/Origin | LFCSP 2x3,3x3 Assembly Test Site Transfer 18/Oct/2013 Assembly/Test Site Revision B 28/Apr/2014 Assembly/Test Site Revision C 06/Aug/2014 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 3.3V, 2.5V, 1.8V | |
| Current - Output | 200mA | |
| Voltage - Dropout (Typical) | 0.11V @ 200mA, 0.11V @ 200mA, - | |
| Number of Regulators | 3 | |
| Voltage - Input | 1.8 V ~ 5.5 V | |
| Current - Limit (Min) | 250mA | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-WFQFN Exposed Pad, CSP | |
| Supplier Device Package | 16-LFCSP-WQ (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADP322ACPZ-135-R7 | |
| Related Links | ADP322AC, ADP322ACPZ-135-R7 Datasheet, Analog Distributor | |
ADP322ACPZ-135-R7 Details Description
