Analog ADR5040BKSZ-REEL7
- Mfg. Part Number
- ADR5040BKSZ-REEL7
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 2.048V SC70
- Datasheet Download
- ADR5040BKSZ-REEL7.pdf
Availability of ADR5040BKSZ-REEL7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.43890
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADR5040BKSZ-REEL7, we specialize in Analog all series electronic components. ADR5040BKSZ-REEL7 can be shipped within 24 hours after order. If you have any demands for ADR5040BKSZ-REEL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADR5040BKSZ-REEL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADR5040BKSZ-REEL7
| Internal Part Number | EIS-ADR5040BKSZ-REEL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Renewable Energy—Solar PV Solutions | |
| PCN Design/Specification | ADR504x Die Update 12/Sep/2014 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | ADR504 | |
| Packaging | Tape & Reel (TR) | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 2.048V | |
| Voltage - Output (Max) | - | |
| Current - Output | 15mA | |
| Tolerance | ±0.1% | |
| Temperature Coefficient | 75ppm/°C | |
| Noise - 0.1Hz to 10Hz | 2.8µVrms | |
| Noise - 10Hz to 10kHz | 120µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 60µA | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-70, SOT-323 | |
| Supplier Device Package | SC-70-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADR5040BKSZ-REEL7 | |
| Related Links | ADR5040B, ADR5040BKSZ-REEL7 Datasheet, Analog Distributor | |
ADR5040BKSZ-REEL7 Details Description
