Analog ADR512ART-R2
- Mfg. Part Number
- ADR512ART-R2
- Manufacturer
- Analog
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 1.2V SOT23-3
- Datasheet Download
- ADR512ART-R2.pdf
Availability of ADR512ART-R2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADR512ART-R2, we specialize in Analog all series electronic components. ADR512ART-R2 can be shipped within 24 hours after order. If you have any demands for ADR512ART-R2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADR512ART-R2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADR512ART-R2
| Internal Part Number | EIS-ADR512ART-R2 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Versatile High Precision Programmable Current Sources Using DACs, Op Amps, and MOSFET Transistors (CN0151) | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 1.2V | |
| Voltage - Output (Max) | - | |
| Current - Output | 10mA | |
| Tolerance | ±0.3% | |
| Temperature Coefficient | 60ppm/°C | |
| Noise - 0.1Hz to 10Hz | 4µVp-p | |
| Noise - 10Hz to 10kHz | - | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 100µA | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADR512ART-R2 | |
| Related Links | ADR512, ADR512ART-R2 Datasheet, Analog Distributor | |
ADR512ART-R2 Details Description
