Analog ADUM1201WSRZ-RL7
- Mfg. Part Number
- ADUM1201WSRZ-RL7
- Manufacturer
- Analog
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 2.5KV GEN PURP 8SOIC
- Datasheet Download
- ADUM1201WSRZ-RL7.pdf
Availability of ADUM1201WSRZ-RL7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADUM1201WSRZ-RL7, we specialize in Analog all series electronic components. ADUM1201WSRZ-RL7 can be shipped within 24 hours after order. If you have any demands for ADUM1201WSRZ-RL7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADUM1201WSRZ-RL7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADUM1201WSRZ-RL7
| Internal Part Number | EIS-ADUM1201WSRZ-RL7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | HEV/EV Li-Ion Battery Management Solution RF Signal Source Solutions | |
| Video File | iCoupler Digital Isolators Meet Strict HEV/EV Requirements ezLINX™ iCoupler® Isolated Interface Development Environment iCoupler® Digital Isolators in Motor Control Designs | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | iCoupler® | |
| Packaging | Cut Tape (CT) | |
| Technology | Magnetic Coupling | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 2 | |
| Inputs - Side 1/Side 2 | 1/1 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 1Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 150ns, 150ns | |
| Pulse Width Distortion (Max) | 40ns | |
| Rise / Fall Time (Typ) | 10ns, 10ns | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADUM1201WSRZ-RL7 | |
| Related Links | ADUM1201, ADUM1201WSRZ-RL7 Datasheet, Analog Distributor | |
