Analog ADUM5200CRWZ-RL
- Mfg. Part Number
- ADUM5200CRWZ-RL
- Manufacturer
- Analog
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 2.5KV GEN PURP 16SOIC
- Datasheet Download
- ADUM5200CRWZ-RL.pdf
Availability of ADUM5200CRWZ-RL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.97645
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ADUM5200CRWZ-RL, we specialize in Analog all series electronic components. ADUM5200CRWZ-RL can be shipped within 24 hours after order. If you have any demands for ADUM5200CRWZ-RL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ADUM5200CRWZ-RL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ADUM5200CRWZ-RL
| Internal Part Number | EIS-ADUM5200CRWZ-RL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Renewable Energy—Solar PV Solutions | |
| Video File | iCoupler Digital Isolators Meet Strict HEV/EV Requirements | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | IsoPower®, iCoupler® | |
| Packaging | Tape & Reel (TR) | |
| Technology | Magnetic Coupling | |
| Type | General Purpose | |
| Isolated Power | Yes | |
| Number of Channels | 2 | |
| Inputs - Side 1/Side 2 | 2/0 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 25Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns | |
| Pulse Width Distortion (Max) | 6ns | |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns | |
| Voltage - Supply | 3.3V, 5V | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ADUM5200CRWZ-RL | |
| Related Links | ADUM520, ADUM5200CRWZ-RL Datasheet, Analog Distributor | |
ADUM5200CRWZ-RL Details Description
