Diodes Incorporated AH1815-P-B
- Mfg. Part Number
- AH1815-P-B
- Manufacturer
- Diodes Incorporated
- Product Category
- Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs)
- Brief Description
- IC HALL SENSR OMNIPLOR SW
- Datasheet Download
- AH1815-P-B.pdf
Availability of AH1815-P-B
Available Quantity
6005 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.26130
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AH1815-P-B, we specialize in Diodes Incorporated all series electronic components. AH1815-P-B can be shipped within 24 hours after order. If you have any demands for AH1815-P-B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AH1815-P-B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AH1815-P-B
| Internal Part Number | EIS-AH1815-P-B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Sensors, Transducers | |
| Family | Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs) | |
| Series | - | |
| Packaging | * | |
| Sensing Range | ±395G Trip, ±355G Release | |
| Type | Omnipolar Switch | |
| Voltage - Supply | 2.5 V ~ 5.5 V | |
| Current - Supply | 3mA | |
| Current - Output (Max) | 2.5mA | |
| Output Type | Open Drain | |
| Features | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | * | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AH1815-P-B | |
| Related Links | AH181, AH1815-P-B Datasheet, Diodes Incorporated Distributor | |
AH1815-P-B Details Description
