Diodes Incorporated AH3774-W-7
- Mfg. Part Number
- AH3774-W-7
- Manufacturer
- Diodes Incorporated
- Product Category
- Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs)
- Brief Description
- HALL LATCH SWITCH SC59
- Datasheet Download
- AH3774-W-7.pdf
Availability of AH3774-W-7
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24613
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AH3774-W-7, we specialize in Diodes Incorporated all series electronic components. AH3774-W-7 can be shipped within 24 hours after order. If you have any demands for AH3774-W-7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AH3774-W-7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AH3774-W-7
| Internal Part Number | EIS-AH3774-W-7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | AH377 and AH378 Hall Effect Latch IC's | |
| Standard Package | 3,000 | |
| Category | Sensors, Transducers | |
| Family | Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Sensing Range | 60G Trip, -60G Release | |
| Type | Bipolar Latch | |
| Voltage - Supply | 3 V ~ 28 V | |
| Current - Supply | 3mA | |
| Current - Output (Max) | 60mA | |
| Output Type | Open Drain | |
| Features | Temperature Compensation | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SC-59 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AH3774-W-7 | |
| Related Links | AH377, AH3774-W-7 Datasheet, Diodes Incorporated Distributor | |
AH3774-W-7 Details Description
