Abracon Corporation AISC-1008-2R2G-T
- Mfg. Part Number
- AISC-1008-2R2G-T
- Manufacturer
- Abracon Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2UH 280MA 2.8 OHM
- Datasheet Download
- AISC-1008-2R2G-T.pdf
Availability of AISC-1008-2R2G-T
Available Quantity
19020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.09800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AISC-1008-2R2G-T, we specialize in Abracon Corporation all series electronic components. AISC-1008-2R2G-T can be shipped within 24 hours after order. If you have any demands for AISC-1008-2R2G-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AISC-1008-2R2G-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AISC-1008-2R2G-T
| Internal Part Number | EIS-AISC-1008-2R2G-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | AISC-1008.pdfAISC-1008.stp | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | AISC-1008 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ceramic | |
| Inductance | 2.2µH | |
| Tolerance | ±2% | |
| Current Rating | 280mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 2.8 Ohm Max | |
| Q @ Freq | 28 @ 50MHz | |
| Frequency - Self Resonant | 100MHz | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 7.9MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1008 (2520 Metric) | |
| Size / Dimension | 0.115" L x 0.110" W (2.92mm x 2.79mm) | |
| Height - Seated (Max) | 0.090" (2.29mm) | |
| Supplier Device Package | 1008 (2520 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AISC-1008-2R2G-T | |
| Related Links | AISC-100, AISC-1008-2R2G-T Datasheet, Abracon Corporation Distributor | |
AISC-1008-2R2G-T Details Description
