Panasonic Electric Works AM50624A33-A
- Mfg. Part Number
- AM50624A33-A
- Manufacturer
- Panasonic Electric Works
- Product Category
- Snap Action, Limit Switches
- Brief Description
- AM5 SWITCH 6A SPST-NC SIM RLLR L
- Datasheet Download
- AM50624A33-A.pdf
Availability of AM50624A33-A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AM50624A33-A, we specialize in Panasonic Electric Works all series electronic components. AM50624A33-A can be shipped within 24 hours after order. If you have any demands for AM50624A33-A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AM50624A33-A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AM50624A33-A
| Internal Part Number | EIS-AM50624A33-A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | AM5 | |
| Packaging | Bulk | |
| Circuit | SPST-NC | |
| Switch Function | On-Mom | |
| Current Rating | 6A (AC), 500mA (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Lever, Simulated Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Solder, Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 30gf | |
| Release Force | 5gf | |
| Pretravel | 0.125" (3.2mm) | |
| Differential Travel | 0.040" (1.0mm) | |
| Overtravel | 0.055" (1.4mm) | |
| Operating Position | 0.730" (18.5mm) | |
| Mechanical Life | 10,000,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -25°C ~ 105°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AM50624A33-A | |
| Related Links | AM5062, AM50624A33-A Datasheet, Panasonic Electric Works Distributor | |
AM50624A33-A Details Description
