Honeywell Sensing and Productivity Solutions AML21MBE2DC
- Mfg. Part Number
- AML21MBE2DC
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON 4PDT 0.1A 125V
- Datasheet Download
- AML21MBE2DC.pdf
Availability of AML21MBE2DC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 107.25000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AML21MBE2DC, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. AML21MBE2DC can be shipped within 24 hours after order. If you have any demands for AML21MBE2DC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AML21MBE2DC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AML21MBE2DC
| Internal Part Number | EIS-AML21MBE2DC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | AML Series LED Appl Note | |
| Design Resources | AML/MML Series Tech Guide | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | AML21 | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | 4PDT | |
| Switch Function | On-Mom | |
| Current Rating | 100mA (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Rectangular, Button (Not Included) | |
| Color - Actuator/Cap | - | |
| Illumination Type, Color | Incandescent | |
| Illumination Voltage (Nominal) | 28 VAC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | - | |
| Features | Full Guard Bezel | |
| Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
| Operating Temperature | - | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AML21MBE2DC | |
| Related Links | AML21, AML21MBE2DC Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
AML21MBE2DC Details Description
