Honeywell Sensing and Productivity Solutions AML23GBC2AA04
- Mfg. Part Number
- AML23GBC2AA04
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SPDT 3A 125V
- Datasheet Download
- AML23GBC2AA04.pdf
Availability of AML23GBC2AA04
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 64.94000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AML23GBC2AA04, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. AML23GBC2AA04 can be shipped within 24 hours after order. If you have any demands for AML23GBC2AA04, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AML23GBC2AA04 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AML23GBC2AA04
| Internal Part Number | EIS-AML23GBC2AA04 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | AML/MML Series Tech Guide | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | AML23 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 3A (AC), 2A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 24V | |
| Actuator Type | Paddle | |
| Actuator Length | - | |
| Illumination | Illuminated | |
| Illumination Type, Color | Incandescent | |
| Illumination Voltage (Nominal) | 14 VAC | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
| Bushing Thread | - | |
| Ingress Protection | - | |
| Features | - | |
| Actuator Material | - | |
| Electrical Life | 25,000 Cycles | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AML23GBC2AA04 | |
| Related Links | AML23G, AML23GBC2AA04 Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
AML23GBC2AA04 Details Description
