Alpha & Omega Semiconductor Inc. AOZ8206DI-05
- Mfg. Part Number
- AOZ8206DI-05
- Manufacturer
- Alpha & Omega Semiconductor Inc.
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 5VWM 9VC 6DFN
- Datasheet Download
- AOZ8206DI-05.pdf
Availability of AOZ8206DI-05
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.11625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AOZ8206DI-05, we specialize in Alpha & Omega Semiconductor Inc. all series electronic components. AOZ8206DI-05 can be shipped within 24 hours after order. If you have any demands for AOZ8206DI-05, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AOZ8206DI-05 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AOZ8206DI-05
| Internal Part Number | EIS-AOZ8206DI-05 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | AOS Green Policy | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 6 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 5V (Max) | |
| Voltage - Breakdown (Min) | 6V | |
| Voltage - Clamping (Max) @ Ipp | 9V | |
| Current - Peak Pulse (10/1000µs) | 12A (100ns) | |
| Power - Peak Pulse | - | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | 17pF @ 1MHz | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-UFDFN Exposed Pad | |
| Supplier Device Package | 6-DFN | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AOZ8206DI-05 | |
| Related Links | AOZ820, AOZ8206DI-05 Datasheet, Alpha & Omega Semiconductor Inc. Distributor | |
