Abracon Corporation AP2S3EJ
- Mfg. Part Number
- AP2S3EJ
- Manufacturer
- Abracon Corporation
- Product Category
- Programmable Oscillators
- Brief Description
- OSCILLATOR PROG 3.3V +-20PPM SMD
- Datasheet Download
- AP2S3EJ.pdf
Availability of AP2S3EJ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AP2S3EJ, we specialize in Abracon Corporation all series electronic components. AP2S3EJ can be shipped within 24 hours after order. If you have any demands for AP2S3EJ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AP2S3EJ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AP2S3EJ
| Internal Part Number | EIS-AP2S3EJ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS2/REACH Compliance | |
| 3D Model | AP2S.pdfAP2S.stp | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | AP2S | |
| Packaging | Bulk | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 3MHz ~ 110MHz | |
| Function | Enable/Disable | |
| Output | CMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±20ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Spread Spectrum Bandwidth | - | |
| Current - Supply (Max) | 25mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Height | 0.035" (0.90mm) | |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Current - Supply (Disable) (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AP2S3EJ | |
| Related Links | AP2, AP2S3EJ Datasheet, Abracon Corporation Distributor | |
AP2S3EJ Details Description
