Panasonic Electric Works APT1221AX
- Mfg. Part Number
- APT1221AX
- Manufacturer
- Panasonic Electric Works
- Product Category
- Optoisolators - Triac, SCR Output
- Brief Description
- OPTOISOLATOR 5KV TRIAC 4DIP
- Datasheet Download
- APT1221AX.pdf
Availability of APT1221AX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of APT1221AX, we specialize in Panasonic Electric Works all series electronic components. APT1221AX can be shipped within 24 hours after order. If you have any demands for APT1221AX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- APT1221AX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
APT1221AX
| Internal Part Number | EIS-APT1221AX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Triac, SCR Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Output Type | Triac | |
| Zero Crossing Circuit | No | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5000Vrms | |
| Voltage - Off State | 600V | |
| Static dV/dt (Min) | 500V/µs | |
| Current - LED Trigger (Ift) (Max) | 10mA | |
| Current - On State (It (RMS)) (Max) | 100mA | |
| Current - Hold (Ih) | 3.5mA | |
| Turn On Time | 100µs (Max) | |
| Voltage - Forward (Vf) (Typ) | 1.21V | |
| Current - DC Forward (If) (Max) | 50mA | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Through Hole | |
| Package / Case | 4-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 4-DIP | |
| Approvals | cUR, VDE | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | APT1221AX | |
| Related Links | APT1, APT1221AX Datasheet, Panasonic Electric Works Distributor | |
