Microsemi Power Products APTGT200DA60T3AG
- Mfg. Part Number
- APTGT200DA60T3AG
- Manufacturer
- Microsemi Power Products
- Product Category
- IGBTs - Modules
- Brief Description
- MOD IGBT 600V 290A SP3
- Datasheet Download
- APTGT200DA60T3AG.pdf
Availability of APTGT200DA60T3AG
Available Quantity
5028 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 50.50224
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of APTGT200DA60T3AG, we specialize in Microsemi Power Products all series electronic components. APTGT200DA60T3AG can be shipped within 24 hours after order. If you have any demands for APTGT200DA60T3AG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- APTGT200DA60T3AG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
APTGT200DA60T3AG
| Internal Part Number | EIS-APTGT200DA60T3AG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | SP3F Plastic Frame Update 16/Jul/2015 | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | IGBTs - Modules | |
| Series | - | |
| IGBT Type | Trench Field Stop | |
| Configuration | Single | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 290A | |
| Power - Max | 750W | |
| Vce(on) (Max) @ Vge, Ic | 1.9V @ 15V, 200A | |
| Current - Collector Cutoff (Max) | 250µA | |
| Input Capacitance (Cies) @ Vce | 12.3nF @ 25V | |
| Input | Standard | |
| NTC Thermistor | Yes | |
| Mounting Type | Chassis Mount | |
| Package / Case | SP3 | |
| Supplier Device Package | SP3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | APTGT200DA60T3AG | |
| Related Links | APTGT200, APTGT200DA60T3AG Datasheet, Microsemi Power Products Distributor | |
