Panasonic Electric Works AQ2A1-C2-T5VDC
- Mfg. Part Number
- AQ2A1-C2-T5VDC
- Manufacturer
- Panasonic Electric Works
- Product Category
- Solid State Relays
- Brief Description
- SSR 2A 125VAC 5VDC RANDOM
- Datasheet Download
- AQ2A1-C2-T5VDC.pdf
Availability of AQ2A1-C2-T5VDC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.06850
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AQ2A1-C2-T5VDC, we specialize in Panasonic Electric Works all series electronic components. AQ2A1-C2-T5VDC can be shipped within 24 hours after order. If you have any demands for AQ2A1-C2-T5VDC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AQ2A1-C2-T5VDC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AQ2A1-C2-T5VDC
| Internal Part Number | EIS-AQ2A1-C2-T5VDC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | PhotoMOS Schematic & Wiring Diagrams | |
| Standard Package | 20 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | AQ8 | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC | |
| On-State Resistance | - | |
| Load Current | 2A | |
| Voltage - Input | 4 ~ 6VDC | |
| Voltage - Load | 75 ~ 125 V | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Package / Case | 4-SIP | |
| Supplier Device Package | 4-SIL | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AQ2A1-C2-T5VDC | |
| Related Links | AQ2A1-C, AQ2A1-C2-T5VDC Datasheet, Panasonic Electric Works Distributor | |
AQ2A1-C2-T5VDC Details Description
