Abracon Corporation ASV2-25.000MHZ-C-L1-T
- Mfg. Part Number
- ASV2-25.000MHZ-C-L1-T
- Manufacturer
- Abracon Corporation
- Product Category
- Oscillators
- Brief Description
- OSC XO 25.000MHZ HCMOS SMD
- Datasheet Download
- ASV2-25.000MHZ-C-L1-T.pdf
Availability of ASV2-25.000MHZ-C-L1-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.76700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ASV2-25.000MHZ-C-L1-T, we specialize in Abracon Corporation all series electronic components. ASV2-25.000MHZ-C-L1-T can be shipped within 24 hours after order. If you have any demands for ASV2-25.000MHZ-C-L1-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ASV2-25.000MHZ-C-L1-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ASV2-25.000MHZ-C-L1-T
| Internal Part Number | EIS-ASV2-25.000MHZ-C-L1-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | ASV2.pdfASV2.stp | |
| Standard Package | 1,000 | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Series | ASV2 | |
| Packaging | Tape & Reel (TR) | |
| Type | XO (Standard) | |
| Frequency | 25MHz | |
| Function | Tri-State (Output Enable) | |
| Output | HCMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -10°C ~ 70°C | |
| Current - Supply (Max) | 20mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) | |
| Height | 0.055" (1.40mm) | |
| Package / Case | 4-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | 10µA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ASV2-25.000MHZ-C-L1-T | |
| Related Links | ASV2-25.00, ASV2-25.000MHZ-C-L1-T Datasheet, Abracon Corporation Distributor | |
